Power supply FTPC50V12-D, 12V, ,5-4,16A, 50W, DIM

Reference: 05-001186

Power supply FTPC50V12-D,

180-264 V AC,

12 V DC, 0,5-4,16 A, 50W, IP4X, DIM

Delivery time 1...2 weeks Warning: Last items in stock!

27,93 €

27,93 € per tk

The minimum purchase order quantity for the product is 10

Quantity

Rating: Be the first to write a review!

Model	FTPC50V12-D
Minimum input voltage - (V AC)	180
Input voltage - (V AC)	230
Maximum input voltage - (V AC)	264
Output power - (W)	50
Power supply type	Constant voltage
Output voltage - (V DC)	12
Min output current - (A)	0,5
Max output current - (A)	4,16
Power factor - PF (cos φ)	0,9
Ambient temperature - (° C)	-20 + 45
Efficiency - (%)	85
Overvoltage protection	18 V, Lülitub välja. Peale ülepinge kadumist ei käivitu ise.
Short circuit protection	Hiccup - auto recovery.
Overload protection	120 %, Hiccup - auto recovery.
Temperature protection	115 ± 10°C, auto recovery.
Dimming	yes
Can drive	Mono
Triac	Yes
Dimming range	1 - 100 %
Dimming step	smooth
Width - (mm)	58
Length - (mm)	178
Height - (mm)	22
Weight - (g1pc)	200
Ingress protection - (IP)	4X
Fixing	srew fixing
Connection	screw terminal
Warranty - (y)	2
